| Broj dijela | LP133WH1-TLA1 |
| Marka | LG Display |
| Veličina | 13.3 |
| Primjena | NBPC |
| Rezolucija | 1366×768 |
| Sastav | LCM |
| Svjetlina | 200 |
| CR | 300:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | LG Display |
| panelni model | LP133WH1-TLA1 1 Compatible model |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 13.3 inch |
| rezolucija | 1366(RGB)×768 , WXGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 293.42×164.97 mm |
| obris | 307.6×183.1×5.5 mm |
| stil oblika | Wedge (PCBA Bent, Depth ≥5.2mm) |
| površinski | Glare (Haze 0%), Hard coating (3H) |
| svjetlina | 200 cd/m² (Typ.) |
| omjer kontrasta | 300:1 (Min.) |
| boje prikaza | 262K (6-bit), CIE193145% |
| vrijeme odziva | 16 (Typ.)(Tr+Td) |
| kut gledanja | 40/40/10/30 (Min.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | WLEDEmbedded (LED Driver) |
| signalno sučelje | LVDS (1 ch, 6-bit), 40 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | NBPC |
| LP133WF1-SPA1 | LG Display | 13.3 | 1920×1080 |
| LP133WF2-SPA1 | LG Display | 13.3 | 1920×1080 |
| LP133WH2-SPA2 | LG Display | 13.3 | 1366×768 |
| LP133WH2-TLA3 | LG Display | 13.3 | 1366×768 |
| LP133WH2-TLB2 | LG Display | 13.3 | 1366×768 |
| LP133WH2-TLL1 | LG Display | 13.3 | 1366×768 |
| LP133WH2-TLL3 | LG Display | 13.3 | 1366×768 |
| LP133WH2-TLL4 | LG Display | 13.3 | 1366×768 |
| LP133WX1-TLB1 | LG Display | 13.3 | 1280×800 |
| LP133WX3-TLA6 | LG Display | 13.3 | 1280×800 |
| B140HAN01.0 | AUO | 14.0 | 1920×1080 |
| B141EW05 V4 | AUO | 14.1 | 1280×800 |
| LP101WH1-TLA2 | LG Display | 10.1 | 1366×768 |
| LP156WF4-SLC1 | LG Display | 15.6 | 1920×1080 |
| LP171WU5-TLA1 | LG Display | 17.1 | 1920×1200 |
| LTN154X5-L02 | Samsung | 15.4 | 1280×800 |
| LTN173HT02-C01 | Samsung | 17.3 | 1920×1080 |
| M116NWR1 R3 | IVO | 11.6 | 1366×768 |
| N141I6-D11 | Innolux | 14.1 | 1280×800 |
| QD14FL02 Rev.01 | QDI | 14.1 | 1400×1050 |
