| Broj dijela | LMS350GF03-001 |
| Marka | Samsung |
| Veličina | 3.5 |
| Primjena | PP |
| Rezolucija | 320×240 |
| Sastav | LCM |
| Svjetlina | 320 |
| CR | 300:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | SAMSUNG |
| panelni model | LMS350GF03-001 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 3.5 inch |
| rezolucija | 320(RGB)×240 , QVGA |
| način prikaza | TN, Normally White, TMR |
| aktivno područje | 70.08×52.56 mm |
| obris | 76.9×63.9×4.45 mm |
| površinski | |
| svjetlina | 320 cd/m² (Typ.) |
| omjer kontrasta | 300 : 1 (Typ.) |
| boje prikaza | 16.7M (8-bit) |
| vrijeme odziva | 25 (Typ.)(Tr+Td) |
| kut gledanja | 60/60/50/55 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 6S1PWLEDWithout Driver |
| signalno sučelje | Parallel RGB (1 ch, 8-bit) + SPI, 71 pins |
| ulazni napon | 3.3/3.3V (Typ.)(VDD/VCI) |
| primjena | PP |
