| Broj dijela | KCG047QV1AA-A21 |
| Marka | Kyocera |
| Veličina | 4.7 |
| Primjena | IA |
| Rezolucija | 320×240 |
| Sastav | LCM |
| Svjetlina | 160 |
| CR | 30:1 |
| Boje | Color |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | Parallel Data |
| marka panela | Kyocera |
| panelni model | KCG047QV1AA-A21 |
| vrsta panela | CSTN-LCD , LCM |
| veličina ploče | 4.7 inch |
| rezolucija | 320(RGB)×240 , QVGA |
| način prikaza | STN, Normally Black, Transmissive |
| aktivno područje | 95.98×71.98 mm |
| obris | 122.4×90×11.4 mm |
| površinski | Antiglare |
| svjetlina | 160 cd/m² (Typ.) |
| omjer kontrasta | 30:1 (Typ.) |
| boje prikaza | Color |
| vrijeme odziva | 190/180 (Typ.)(Tr/Td) |
| kut gledanja | 50/50/20/30 (Typ.)(CR≥2)(L/R/U/D) |
| frekvencija | 75Hz |
| tip svjetiljke | 1 pcsCCFLOptional |
| signalno sučelje | Parallel Data (8-bit), 20 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | IA |
| AMS465GS53 | Samsung | 4.7 | 720×1280 |
| DMF50081NB-FW | Kyocera | 4.7 | 320×240 |
| H466TAN01.0 | AUO | 4.7 | 720×1280 |
| KCG047QV1AA-A21 | Kyocera | 4.7 | 320×240 |
| KCG047QV1AA-A210 | Kyocera | 4.7 | 320×240 |
| LH470WX6-SJ11 | LG Display | 4.7 | 750×1334 |
| LJ32H028 | SHARP | 4.7 | 320×240 |
| TM047NBH01 | Tianma | 4.7 | 480×272 |
| TM047NDH01 | Tianma | 4.7 | 480×272 |
| TS047NAARB01-00 | Tianma | 4.7 | 480×272 |
| A050AVV50R0 | Aptus | 5.0 | 800×480 |
| G070VTN01.0 | AUO | 7.0 | 800×480 |
| LM240WU8-SLA2 | LG Display | 24.0 | 1920×1200 |
| LM641836R | SHARP | 9.4 | 640×480 |
| LQ10D341 | SHARP | 10.4 | 640×480 |
| M101GWN9 R0 | IVO | 10.1 | 1024×600 |
| NL10276BC20-04 | NLT | 10.4 | 1024×768 |
| OEL9M0065-R-E | Other | 2.7 | 256×64 |
| OEL9M0072-B-E | Other | 1.54 | 128×64 |
| SP14Q001-X | KOE | 5.7 | 320×240 |
