| Broj dijela | HT260WX2-101 |
| Marka | BOE |
| Veličina | 26.0 |
| Primjena | LCTV |
| Rezolucija | 1366×768 |
| Sastav | CELL |
| Svjetlina | 0 |
| CR | 800:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | No B/L |
| Sučelje | LVDS |
| marka panela | BOE |
| panelni model | HT260WX2-101 |
| vrsta panela | a-Si TFT-LCD , CELL |
| veličina ploče | 26.0 inch |
| rezolucija | 1366(RGB)×768 , WXGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 575.769×323.712 mm |
| obris | 592×339.8 mm |
| površinski | Antiglare (Haze 25%), Hard coating (3H) |
| dubina stakla | 0.70+0.70 mm |
| transmisivnost | 7.05% (Typ.)(with Polarizer) |
| omjer kontrasta | 800:1 (Typ.) |
| boje prikaza | 16.7M (6-bit + Hi-FRC), CIE193172% |
| vrijeme odziva | 5 (Typ.)(G to G) |
| kut gledanja | 80/80/80/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| signalno sučelje | LVDS (1 ch, 8-bit), 30 pins |
| ulazni napon | 12.0V (Typ.) |
| primjena | LCTV |
