| Broj dijela | HT260WX1-100 |
| Marka | BOE |
| Veličina | 26.0 |
| Primjena | LCTV |
| Rezolucija | 1366×768 |
| Sastav | LCM |
| Svjetlina | 450 |
| CR | 800:1 |
| Boje | 16.2M |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | LVDS |
| marka panela | BOE |
| panelni model | HT260WX1-100 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 26.0 inch |
| rezolucija | 1366(RGB)×768 , WXGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 575.769×323.712 mm |
| obris | 626×373×43.5 mm |
| površinski | Antiglare (Haze 25%), Hard coating (3H) |
| svjetlina | 450 cd/m² (Typ.) |
| omjer kontrasta | 800:1 (Typ.) |
| boje prikaza | 16.2M (6-bit + FRC) |
| vrijeme odziva | 5 (Typ.)(G to G) |
| kut gledanja | 80/80/80/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 4 pcsCCFLWithout Driver |
| signalno sučelje | LVDS (1 ch, 8-bit), 30 pins |
| ulazni napon | 5.0V (Typ.) |
| primjena | LCTV |
