| Broj dijela | HT190WG1-600 |
| Marka | BOE |
| Veličina | 19.0 |
| Primjena | DMPC |
| Rezolucija | 1440×900 |
| Sastav | LCM |
| Svjetlina | 300 |
| CR | 1000:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | LVDS |
| marka panela | BOE |
| panelni model | HT190WG1-600 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 19.0 inch |
| rezolucija | 1440(RGB)×900 , WXGA+ |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 408.24×255.15 mm |
| obris | 428×278×19 mm |
| površinski | Antiglare (Haze 25%), Hard coating (3H) |
| svjetlina | 300 cd/m² (Typ.) |
| omjer kontrasta | 1000:1 (Typ.) |
| boje prikaza | 16.7M (6-bit + Hi-FRC), CIE193172% |
| vrijeme odziva | 1.5/3.5 (Typ.)(Tr/Td) |
| kut gledanja | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 4 pcsCCFLWithout Driver |
| signalno sučelje | LVDS (2 ch, 8-bit), 30 pins |
| ulazni napon | 5.0V (Typ.) |
| primjena | DMPC |
| HT190WG1-100 | BOE | 19.0 | 1440×900 |
| HT190WG1-600 | BOE | 19.0 | 1440×900 |
| HT190WG1-602 | BOE | 19.0 | 1440×900 |
| HT190WG3-100 | BOE | 19.0 | 1440×900 |
| HT190WG3-101 | BOE | 19.0 | 1440×900 |
| HT190WG3-500 | BOE | 19.0 | 1440×900 |
| LM190E08-TLJ7 | LG Display | 19.0 | 1280×1024 |
| LQ190E1LX75 | SHARP | 19.0 | 1280×1024 |
| LTM190BT03 | Samsung | 19.0 | 1440×900 |
| M190A1-L0A | Innolux | 19.0 | 1440×900 |
| HT170EX1-300 | BOE | 17.0 | 1280×1024 |
| LM171WX3-TLA1 | LG Display | 17.1 | 1440×900 |
| LM201U02-A3C3 | LG Display | 20.1 | 1600×1200 |
| LM215WF3-SLA1 | LG Display | 21.5 | 1920×1080 |
| LTM170EU-L11 | Samsung | 17.0 | 1280×1024 |
| LTM170EU-L31 | Samsung | 17.0 | 1280×1024 |
| M240HTD01.0 | AUO | 24.0 | 1920×1080 |
| MV238FHM-N10 | BOE | 23.8 | 1920×1080 |
| P236MWF1 R2 | IVO | 23.6 | 1920×1080 |
| TMS156WX1-02TC | Tianma | 15.6 | 1366×768 |
