| Broj dijela | TMS156WX1-02TC |
| Marka | Tianma |
| Veličina | 15.6 |
| Primjena | DMPC |
| Rezolucija | 1366×768 |
| Sastav | CELL |
| Svjetlina | 0 |
| CR | 500:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | No B/L |
| Sučelje | LVDS |
| marka panela | AVIC |
| panelni model | TMS156WX1-02TC |
| vrsta panela | a-Si TFT-LCD , CELL |
| veličina ploče | 15.6 inch |
| rezolucija | 1366(RGB)×768 , WXGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 344.232×193.536 mm |
| površinski | |
| omjer kontrasta | 500:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193160% |
| vrijeme odziva | 2/6 (Typ.)(Tr/Td) |
| kut gledanja | 45/45/20/45 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| signalno sučelje | LVDS (1 ch, 8-bit), 30 pins |
| ulazni napon | 5.0V (Typ.) |
| primjena | DMPC |
