| Broj dijela | DLC1210EIG |
| Marka | Other |
| Veličina | 12.1 |
| Primjena | CNS |
| Rezolucija | 1024×768 |
| Sastav | LCM |
| Svjetlina | 600 |
| CR | 600:1 |
| Boje | 262K/16.2M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | DLC |
| panelni model | DLC1210EIG |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 12.1 inch |
| rezolucija | 1024(RGB)×768 , XGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 245.76×184.32 mm |
| obris | 260.5×204×8.9 mm |
| površinski | |
| svjetlina | 600 cd/m² (Typ.) |
| omjer kontrasta | 600:1 (Typ.) |
| boje prikaza | 262K/16.2M (6-bit / 6-bit + FRC), CIE193163% |
| vrijeme odziva | 5/11 (Typ.)(Tr/Td) |
| kut gledanja | 80/80/70/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | WLEDEmbedded (LED Driver) |
| signalno sučelje | LVDS (1 ch, 6/8-bit), 20 pins |
| ulazni napon | 3.3/5.0V (Typ.)(VCC) |
| primjena | CNS |
