| Broj dijela | DLC1010AZG-1 |
| Marka | Other |
| Veličina | 10.1 |
| Primjena | CNS |
| Rezolucija | 1024×600 |
| Sastav | LCM |
| Svjetlina | 1000 |
| CR | 250:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | DLC |
| panelni model | DLC1010AZG-1 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 10.1 inch |
| rezolucija | 1024(RGB)×600 , WSVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 222.72×125.28 mm |
| obris | 235×149.52 mm |
| površinski | |
| svjetlina | 1000 cd/m² (Typ.) |
| omjer kontrasta | 250:1 (Typ.) |
| boje prikaza | 16.7M (8-bit) |
| vrijeme odziva | |
| kut gledanja | 85/85/85/60 (Typ.)(CR≥10)(L/R/U/D) |
| tip svjetiljke | 3S16PWLEDWithout Driver |
| signalno sučelje | LVDS (1 ch, 8-bit), 30 pins |
| ulazni napon | 3.3/10.5V (Typ.)(VCC/AVDD) |
| primjena | CNS |
| B101EVT05.0 | AUO | 10.1 | 1280×800 |
| DLC1010AZG-1 | Other | 10.1 | 1024×600 |
| DLC1010CIG-6 | Other | 10.1 | 1280×800 |
| DLC1010DZG-T-8 | Other | 10.1 | 1280×800 |
| DLC1010GIG | Other | 10.1 | 1280×800 |
| G101STN01.2 | AUO | 10.1 | 1024×600 |
| HSD101PWW2-A00 | HannStar | 10.1 | 1280×800 |
| LTL101AL06-801 | Samsung | 10.1 | 1280×800 |
| LTN101NT02-W05 | Samsung | 10.1 | 1024×600 |
| M101GWN9 R2 | IVO | 10.1 | 1024×600 |
| A061FW01 V0 | AUO | 6.1 | 480×234 |
| A070VW05 V0 | AUO | 7.0 | 800×480 |
| AM-1024600-070H | Other | 7.0 | 1024×600 |
| CLAA070LD0DCW | CPT | 7.0 | 800×480 |
| DLC0700CZG-6 | Other | 7.0 | 800×480 |
| L5S30883P00 | SANYO | 4.5 | 480×240 |
| LB070WV1-TD03 | LG Display | 7.0 | 800×480 |
| LQ6BW506 | SHARP | 5.8 | 400×234 |
| LTA061B2E0F | TOSHIBA | 6.1 | |
| TFD65W46 | TOSHIBA | 6.5 | 480×234 |
