| Broj dijela | DLC0220BMG |
| Marka | Other |
| Veličina | 2.2 |
| Primjena | MPH |
| Rezolucija | 240×320 |
| Sastav | LCM |
| Svjetlina | 90 |
| CR | 120:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | DLC |
| panelni model | DLC0220BMG 2 Compatible model |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 2.2 inch |
| rezolucija | 240(RGB)×320 , QVGA |
| način prikaza | ECB, Normally White, Transflective |
| aktivno područje | 33.84×45.12 mm |
| obris | 40.6×56.6 mm |
| površinski | Clear, Hard coating (3H) |
| svjetlina | 90 cd/m² (Typ.) |
| omjer kontrasta | 120:1 (Typ.)(Transmissive) |
| boje prikaza | 262K (6-bit), CIE193130% |
| vrijeme odziva | 35 (Typ.)(Tr+Td) |
| kut gledanja | 40/45/48/45 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 4S1PWLEDWithout Driver |
| signalno sučelje | Parallel RGB (1 ch, 6-bit) + SPI, 39 pins |
| ulazni napon | 2.8V (Typ.)(VDD) |
| primjena | MPH |
