| Broj dijela | ET0320A5DM9 |
| Marka | EDT |
| Veličina | 3.2 |
| Primjena | MPH |
| Rezolucija | 240×320 |
| Sastav | LCM |
| Svjetlina | 350 |
| CR | 450:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | CPU |
| marka panela | EDT |
| panelni model | ET0320A5DM9 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 3.2 inch |
| rezolucija | 240(RGB)×320 , QVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 48.6×64.8 mm |
| obris | 55.14×76.8×6 mm |
| površinski | |
| svjetlina | 350 cd/m² (Typ.) |
| omjer kontrasta | 450:1 (Typ.) |
| boje prikaza | 262K (6-bit) |
| vrijeme odziva | 5/15 (Typ.)(Tr/Td) |
| kut gledanja | 63/70/65/72 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 6S1PWLEDWithout Driver |
| signalno sučelje | 8/9/16/18-bit 8080 parallel, 41 pins |
| ulazni napon | 3.3/3.3V (Typ.)(IOVCC/VCC) |
| primjena | MPH |
