| Broj dijela | CLAA057VC01CW |
| Marka | CPT |
| Veličina | 5.7 |
| Primjena | IA |
| Rezolucija | 640×480 |
| Sastav | LCM |
| Svjetlina | 220 |
| CR | 300:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | CPT |
| panelni model | CLAA057VC01CW |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 5.7 inch |
| rezolucija | 640(RGB)×480 , VGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 116.16×87.12 mm |
| obris | 127×100×6.9 mm |
| površinski | Antiglare, Hard coating (3H) |
| svjetlina | 220 cd/m² (Typ.) |
| omjer kontrasta | 300:1 (Typ.) |
| boje prikaza | 262K (6-bit), CIE193150% |
| vrijeme odziva | 20 (Typ.)(Tr+Td) |
| kut gledanja | 70/70/45/55 (Typ.)(CR≥10)(L/R/U/D) |
| tip svjetiljke | WLEDEmbedded (LED Driver) |
| signalno sučelje | TTL (1 ch, 6-bit), 40 pins |
| ulazni napon | 3.3V (Typ.) |
| rohs: | |
| primjena | IA |
