| Broj dijela | AG-320240A4FIQW-K9H-S(N)(R) |
| Marka | AMPIRE |
| Veličina | 5.7 |
| Primjena | IA |
| Rezolucija | 320×240 |
| Sastav | LCM |
| Svjetlina | |
| CR | |
| Boje | Monochrome |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | CPU |
| marka panela | AMPIRE |
| panelni model | AG-320240A4FIQW-K9H-S(N)(R) |
| vrsta panela | FSTN-LCD , LCM |
| veličina ploče | 5.7 inch |
| rezolucija | 320×240 , QVGA |
| način prikaza | STN, Transflective |
| aktivno područje | 115.185×86.385 mm |
| obris | 167×104.7×14.5 mm |
| površinski | |
| svjetlina | |
| omjer kontrasta | |
| boje prikaza | Monochrome |
| vrijeme odziva | 200/200 (Typ.)(Tr/Td) |
| kut gledanja | 30/30/35/30 (Typ.)(CR≥10)(L/R/U/D) |
| tip svjetiljke | 1S6PWLEDWithout Driver |
| signalno sučelje | 8-bit 6080/8080 parallel, 24 pins |
| ulazni napon | 5.0V (Typ.) |
| primjena | IA |
