| Broj dijela | BB050HDG-T40 |
| Marka | BOE |
| Veličina | 5.0 |
| Primjena | MPH |
| Rezolucija | 720×1280 |
| Sastav | OLED |
| Svjetlina | 350 |
| CR | 17000:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | self |
| Sučelje | MIPI |
| marka panela | BOE |
| panelni model | BB050HDG-T40 |
| vrsta panela | AM-OLED , OLED |
| veličina ploče | 5.0 inch |
| rezolucija | 720(RGB)×1280 , WXGA |
| aktivno područje | 61.92×110.08 mm |
| obris | 64.12×116.72 mm |
| površinski | Hard coating |
| svjetlina | 350 cd/m² (Typ.) |
| omjer kontrasta | 17000 : 1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE1931101% |
| kut gledanja | 80/80/80/80 (Min.)(L/R/U/D) |
| frekvencija | 60Hz |
| vozač ic | COG Built-in RM67120 |
| signalno sučelje | MIPI (4 data lanes) |
| ulazni napon | 2.8/1.8/6.0V (Typ.)(VCI/VDDIO/AVDD) |
| primjena | MPH |
