| Broj dijela | B141EW01 V3 |
| Marka | AUO |
| Veličina | 14.1 |
| Primjena | NBPC |
| Rezolucija | 1280×800 |
| Sastav | LCM |
| Svjetlina | 200 |
| CR | 350:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | LVDS |
| marka panela | AUO |
| panelni model | B141EW01 V3 1 Compatible model |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 14.1 inch |
| rezolucija | 1280(RGB)×800 , WXGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 303.36×189.6 mm |
| obris | 319.5×205.5×5.5 mm |
| stil oblika | Wedge (PCBA Bent, Depth ≥5.2mm) |
| površinski | Glare (Haze 0%) |
| svjetlina | 200 cd/m² (Typ.) |
| omjer kontrasta | 350:1 (Typ.) |
| boje prikaza | 262K (6-bit) |
| vrijeme odziva | 15/10 (Typ.)(Tr/Td) |
| kut gledanja | 45/45/20/35 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 1 pcsCCFLWithout Driver |
| signalno sučelje | LVDS (1 ch, 6-bit), 30 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | NBPC |
| B141EW01 V3 | AUO | 14.1 | 1280×800 |
| B141EW02 V3 | AUO | 14.1 | 1280×800 |
| B141EW04 V3 | AUO | 14.1 | 1280×800 |
| B141EW04 V4 | AUO | 14.1 | 1280×800 |
| B141EW04 V5 | AUO | 14.1 | 1280×800 |
| B141EW04 V6 | AUO | 14.1 | 1280×800 |
| B141EW04 V7 | AUO | 14.1 | 1280×800 |
| B141EW05 V0 | AUO | 14.1 | 1280×800 |
| B141EW05 V2 | AUO | 14.1 | 1280×800 |
| B141EW05 V5 | AUO | 14.1 | 1280×800 |
| B141EW04 V6 | AUO | 14.1 | 1280×800 |
| LP133WX2-TLA1 | LG Display | 13.3 | 1280×800 |
| LP133WX3-TLA4 | LG Display | 13.3 | 1280×800 |
| LP154WE2-TLB1 | LG Display | 15.4 | 1680×1050 |
| LP154WP2-TLC2 | LG Display | 15.4 | 1440×900 |
| LTN133AT16-S01 | Samsung | 13.3 | 1280×800 |
| LTN156AT01-U01 | Samsung | 15.6 | 1366×768 |
| LTN160AT01-W01 | Samsung | 16.0 | 1366×768 |
| M116NWR1 R3 | IVO | 11.6 | 1366×768 |
| TV122WXM-NW0 | BOE | 12.2 | 1280×800 |
