| Broj dijela | TV122WXM-NW0 |
| Marka | BOE |
| Veličina | 12.2 |
| Primjena | NBPC |
| Rezolucija | 1280×800 |
| Sastav | LCM |
| Svjetlina | 300 |
| CR | 900:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | eDP |
| marka panela | BOE |
| panelni model | TV122WXM-NW0 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 12.2 inch |
| rezolucija | 1280(RGB)×800 , WXGA |
| način prikaza | ADS, Normally Black, Transmissive |
| aktivno područje | 262.565×164.16 mm |
| obris | 271.06×176.42×2.86 mm |
| površinski | |
| svjetlina | 300 cd/m² (Typ.) |
| omjer kontrasta | 900:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193150% |
| vrijeme odziva | 30 (Typ.)(Tr+Td) |
| kut gledanja | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | WLEDWithout Driver |
| signalno sučelje | eDP (2 Lanes), 39 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | NBPC |
