| Broj dijela | AM480272H3TMQW-T00H |
| Marka | AMPIRE |
| Veličina | 4.3 |
| Primjena | PND |
| Rezolucija | 480×272 |
| Sastav | LCM |
| Svjetlina | 250 |
| CR | 250:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | AMPIRE |
| panelni model | AM480272H3TMQW-T00H |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 4.3 inch |
| rezolucija | 480(RGB)×272 , WQVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 95.04×53.856 mm |
| obris | 105.5×67.2×5.26 mm |
| površinski | Antiglare, Hard coating (3H) |
| svjetlina | 250 cd/m² (Typ.) |
| omjer kontrasta | 250:1 (Typ.) |
| boje prikaza | 16.7M (8-bit) |
| vrijeme odziva | 40 (Typ.)(Tr+Td) |
| kut gledanja | 65/65/45/45 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 7S1PWLEDWithout Driver |
| signalno sučelje | Parallel RGB (1 ch, 8-bit), 54 pins |
| ulazni napon | 3.0V (Typ.) |
| primjena | PND |
