| Broj dijela | AG-12864CYIQY-14H-A(R) |
| Marka | AMPIRE |
| Veličina | 2.7 |
| Primjena | IA |
| Rezolucija | 128×64 |
| Sastav | LCM |
| Svjetlina | 7 |
| CR | 4:1 |
| Boje | Monochrome |
| Pozadinsko osvjetljenje | YG-LED |
| Sučelje | CPU |
| marka panela | AMPIRE |
| panelni model | AG-12864CYIQY-14H-A(R) |
| vrsta panela | STN-LCD , LCM |
| veličina ploče | 2.7 inch |
| rezolucija | 128×64 |
| način prikaza | STN, Yellow/Green (Positive), Transflective |
| aktivno područje | 56.28×38.36 mm |
| obris | 78×70×13 mm |
| površinski | |
| svjetlina | 7 cd/m² (Typ.) |
| omjer kontrasta | 4:1 (Typ.)(Transmissive) |
| boje prikaza | Monochrome |
| vrijeme odziva | 140/240 (Typ.)(Tr/Td) |
| kut gledanja | 35/35/35/40 (Typ.)(CR≥2)(L/R/U/D) |
| frekvencija | 70Hz |
| tip svjetiljke | 2S5PYG-LEDWithout Driver |
| signalno sučelje | 8-bit parallel, 20 pins |
| ulazni napon | 5.0V (Typ.) |
| primjena | IA |
