| Broj dijela | LTM12C275A |
| Marka | TOSHIBA |
| Veličina | 12.1 |
| Primjena | IA |
| Rezolucija | 800×600 |
| Sastav | LCM |
| Svjetlina | 250 |
| CR | 250:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | TTL |
| marka panela | TOSHIBA |
| panelni model | LTM12C275A |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 12.1 inch |
| rezolucija | 800(RGB)×600 , SVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 246×184.5 mm |
| obris | 290×220×15 mm |
| površinski | |
| svjetlina | 250 cd/m² (Typ.) |
| omjer kontrasta | 250:1 (Typ.) |
| boje prikaza | 262K (6-bit) |
| vrijeme odziva | 50/50 (Max.)(Tr/Td) |
| kut gledanja | |
| tip svjetiljke | 2 pcsCCFLWithout Driver |
| signalno sučelje | Parallel RGB (1 ch, 6-bit), 30 pins |
| ulazni napon | 5.0V (Typ.)(VDD) |
| primjena | IA |
| LTM121SI-T01 | Samsung | 12.1 | 800×600 |
| LTM12C268F | TOSHIBA | 12.1 | 800×600 |
| LTM12C275A | TOSHIBA | 12.1 | 800×600 |
| LTM12C278F | TOSHIBA | 12.1 | 800×600 |
| LTM12C283 | TOSHIBA | 12.1 | 800×600 |
| LTM12C285 | TOSHIBA | 12.1 | 800×600 |
| LTM12C289 | TOSHIBA | 12.1 | 800×600 |
| LTM12C318S | TOSHIBA | 12.1 | 1024×768 |
| LTM12C505D | TOSHIBA | 12.1 | 1024×768 |
| LTM12C505T | TOSHIBA | 12.1 | 1024×768 |
| AA043MA01 | Mitsubishi | 4.3 | 800×480 |
| AA084SD01 | Mitsubishi | 8.4 | 800×600 |
| DLC1500AMG-1 | Other | 15.0 | 1024×768 |
| LM-CA53-22NTK | SANYO | 9.4 | 640×480 |
| LM12S471 | SHARP | 12.1 | 800×600 |
| LQ281L1LW12 | SHARP | 28.1 | 2048×2048 |
| LTA104S2-L01 | Samsung | 10.4 | 800×600 |
| NL10276AC30-42C | NLT | 15.0 | 1024×768 |
| NL6448BC33-71 | NLT | 10.4 | 640×480 |
| TM240128ABCWVBYD | Tianma | 4.8 | 240×128 |
