| Broj dijela | VVX10F008B00 |
| Marka | Panasonic |
| Veličina | 10.1 |
| Primjena | PAD |
| Rezolucija | 1920×1200 |
| Sastav | LCM |
| Svjetlina | 385 |
| CR | 900:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | MIPI |
| marka panela | Panasonic |
| panelni model | VVX10F008B00 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 10.1 inch |
| rezolucija | 1920(RGB)×1200 , WUXGA |
| način prikaza | IPS, Normally Black, Transmissive |
| aktivno područje | 217.44×135.9 mm |
| obris | 228.96×148.14×4.29 mm |
| površinski | Hard coating |
| svjetlina | 385 cd/m² (Typ.) |
| omjer kontrasta | 900:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193174% |
| vrijeme odziva | 30 (Max.)(Tr+Td) |
| kut gledanja | 80/80/80/80 (Min.)(CR≥100)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 8S6PWLEDWithout Driver |
| signalno sučelje | MIPI (4 data lanes), 40 pins |
| ulazni napon | 3.7V (Typ.) |
| primjena | PAD |
