| Broj dijela | V460H1-LS1 |
| Marka | Innolux |
| Veličina | 46 |
| Primjena | LCTV |
| Rezolucija | 1920×1080 |
| Sastav | LCM |
| Svjetlina | 350 |
| CR | 6000:1 |
| Boje | 1.07B |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | CHIMEI INNOLUX |
| panelni model | V460H1-LS1 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 46 inch |
| rezolucija | 1920(RGB)×1080 , FHD |
| način prikaza | Super MVA, Normally Black, Transmissive |
| aktivno područje | 1018.08×572.67 mm |
| obris | 1076.5×634.7 mm |
| površinski | Antiglare (Haze 11%), Hard coating (3H) |
| svjetlina | 350 cd/m² (Typ.) |
| omjer kontrasta | 6000:1 (Typ.) |
| boje prikaza | 1.07B (8-bit + Hi-FRC), CIE193172% |
| vrijeme odziva | 6 (Typ.)(G to G) |
| kut gledanja | 88/88/88/88 (Typ.)(CR≥20)(L/R/U/D) |
| frekvencija | 120Hz |
| tip svjetiljke | 4 stringsWLEDEmbedded (LED Driver) |
| signalno sučelje | LVDS (4 ch, 10-bit), 102 pins |
| ulazni napon | 12.0V (Typ.) |
| primjena | LCTV |
| LTA460HM06 | Samsung | 46 | 1920×1080 |
| V460H1-L09 | Innolux | 46 | 1920×1080 |
| V460H1-L12 | Innolux | 46 | 1920×1080 |
| V460H1-LE3 | Innolux | 46 | 1920×1080 |
| V460H1-LH9 | Innolux | 46 | 1920×1080 |
| V460H1-LS1 | Innolux | 46 | 1920×1080 |
| V460H1-LS1 Rev.C6 | Innolux | 46 | 1920×1080 |
| V460H1-LS2 | Innolux | 46 | 1920×1080 |
| V460H1-LS2 Rev.C7 | Innolux | 46 | 1920×1080 |
| V460HK2-LS5 | Innolux | 46 | 1920×1080 |
| LC320WXN-SBA1 | LG Display | 31.5 | 1366×768 |
| LC420WUE-SDP1 | LG Display | 42 | 1920×1080 |
| LC500EUN-SFM1 | LG Display | 50 | 1920×1080 |
| T200XW01 V0 | AUO | 20.0 | 1366×768 |
| T320XVN01.0 CELL | AUO | 31.5 | 1366×768 |
| T400XW01 V2 | AUO | 40 | 1366×768 |
| T460HVF01.1 | AUO | 46 | 1920×1080 |
| T550HVN04.1 | AUO | 55 | 1920×1080 |
| V201B1-L02 | Innolux | 20.1 | 1366×768 |
| V290BJ1-PE1 | Innolux | 29.0 | 1366×768 |
