| Broj dijela | UG-9616TSWBG01 |
| Marka | WiseChip |
| Veličina | 0.84 |
| Primjena | IA |
| Rezolucija | 96×16 |
| Sastav | OLED |
| Svjetlina | 120 |
| CR | 10000:1 |
| Boje | Mono(White) |
| Pozadinsko osvjetljenje | self |
| Sučelje | I²C |
| marka panela | WiseChip |
| panelni model | UG-9616TSWBG01 |
| vrsta panela | PM-OLED , OLED |
| veličina ploče | 0.84 inch |
| rezolucija | 96×16 |
| aktivno područje | 21.104×3.504 mm |
| obris | 29.1×9.2×1.4 mm |
| površinski | |
| svjetlina | 120 cd/m² (Typ.) |
| omjer kontrasta | 10000 : 1 (Typ.) |
| boje prikaza | Mono(White) (1-bit) |
| kut gledanja | |
| vozač ic | Built-in SSD1306 |
| signalno sučelje | I²C, 14 pins |
| ulazni napon | 2.8/7.25V (Typ.)(VDD/VCC) |
| primjena | IA |
