| Broj dijela | TX38D25VM0CAA |
| Marka | KOE |
| Veličina | 14.9 |
| Primjena | IA |
| Rezolucija | 1280×242 |
| Sastav | LCM |
| Svjetlina | 450 |
| CR | 800:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | KOE |
| panelni model | TX38D25VM0CAA |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 14.9 inch |
| rezolucija | 1280(RGB)×242 |
| način prikaza | IPS NP, Normally Black, Transmissive |
| aktivno područje | 372.48×70.42 mm |
| obris | 386.82×85.57 mm |
| površinski | |
| svjetlina | 450 cd/m² (Typ.) |
| omjer kontrasta | 800:1 (Typ.) |
| boje prikaza | 262K (6-bit), CIE193160% |
| vrijeme odziva | 25 (Typ.)(Tr+Td) |
| kut gledanja | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | WLEDEmbedded (LED Driver) |
| signalno sučelje | LVDS (1 ch, 6-bit), 20 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | IA |
