| Broj dijela | TX26D202VM0BAA |
| Marka | KOE |
| Veličina | 10.1 |
| Primjena | IA |
| Rezolucija | 1920×1200 |
| Sastav | LCM |
| Svjetlina | 800 |
| CR | 800:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | KOE |
| panelni model | TX26D202VM0BAA |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 10.1 inch |
| rezolucija | 1920(RGB)×1200 , WUXGA |
| način prikaza | IPS, Normally Black, Transmissive |
| aktivno područje | 217.44×135.9 mm |
| obris | 232.1×153.2×7.62 mm |
| površinski | |
| svjetlina | 800 cd/m² (Typ.) |
| omjer kontrasta | 800:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193155% |
| vrijeme odziva | 25 (Typ.)(Tr+Td) |
| kut gledanja | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | WLEDEmbedded (LED Driver) |
| signalno sučelje | LVDS (2 ch, 8-bit), 50 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | IA |
