| Broj dijela | B101UAN02.1 |
| Marka | AUO |
| Veličina | 10.1 |
| Primjena | PAD |
| Rezolucija | 1920×1200 |
| Sastav | LCM |
| Svjetlina | 400 |
| CR | 800:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | AUO |
| panelni model | B101UAN02.1 1 Compatible model |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 10.1 inch |
| rezolucija | 1920(RGB)×1200 , WUXGA |
| način prikaza | AHVA, Normally Black, Transmissive |
| aktivno područje | 216.81×135.5 mm |
| obris | 229.45×149.2×5 mm |
| površinski | Glare (Haze 0%), Hard coating (3H) |
| svjetlina | 400 cd/m² (Typ.) |
| omjer kontrasta | 800:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193168% |
| vrijeme odziva | 13/12 (Typ.)(Tr/Td) |
| kut gledanja | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 5 stringsWLEDWithout Driver |
| signalno sučelje | LVDS (2 ch, 8-bit), 50 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | PAD |
