| Broj dijela | RX420-Z15 |
| Marka | ROGIN |
| Veličina | 42 |
| Primjena | PID |
| Rezolucija | 1920×1080 |
| Sastav | LCM |
| Svjetlina | 1500 |
| CR | 1200:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | ROGIN |
| panelni model | RX420-Z15 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 42 inch |
| rezolucija | 1920(RGB)×1080 , FHD |
| način prikaza | IPS, Normally Black, Transmissive |
| aktivno područje | 927.94×521.96 mm |
| obris | 956.4×555 mm |
| površinski | Antiglare (Haze 1%), Hard coating (2H) |
| svjetlina | 1500 cd/m² (Typ.) |
| omjer kontrasta | 1200:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193168% |
| vrijeme odziva | 6 (Typ.)(G to G) |
| kut gledanja | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | WLEDEmbedded (LED Driver) |
| signalno sučelje | LVDS (2 ch, 10-bit), 51 pins |
| ulazni napon | 12.0V (Typ.) |
| primjena | PID |
