| Broj dijela | Q070LRE-LA1 |
| Marka | Innolux |
| Veličina | 7.0 |
| Primjena | PAD |
| Rezolucija | 1024×600 |
| Sastav | LCM |
| Svjetlina | 350 |
| CR | 700:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | CHIMEI INNOLUX |
| panelni model | Q070LRE-LA1 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 7.0 inch |
| rezolucija | 1024(RGB)×600 , WSVGA |
| način prikaza | IPS, Normally Black, Transmissive |
| aktivno područje | 153.6×90 mm |
| obris | 164.1×102.6×3.25 mm |
| površinski | Glare (Haze 0%) |
| svjetlina | 350 cd/m² (Typ.) |
| omjer kontrasta | 700:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193150% |
| vrijeme odziva | 30 (Typ.)(Tr+Td) |
| kut gledanja | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 4S5PWLEDWithout Driver |
| signalno sučelje | LVDS (1 ch, 8-bit), 31 pins |
| ulazni napon | 3.7V (Typ.) |
| primjena | PAD |
