| Broj dijela | PW050XS3 |
| Marka | E Ink |
| Veličina | 5.0 |
| Primjena | CNS |
| Rezolucija | 320×220 |
| Sastav | LCM |
| Svjetlina | 350 |
| CR | 350:1 |
| Boje | Full color |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | Analog |
| marka panela | PVI |
| panelni model | PW050XS3 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 5.0 inch |
| rezolucija | 320(RGB)×220 |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 112.5×60.5 mm |
| obris | 125.4×74×6.5 mm |
| površinski | Antiglare |
| svjetlina | 350 cd/m² (Typ.) |
| omjer kontrasta | 350:1 (Typ.) |
| boje prikaza | Full color |
| vrijeme odziva | 15/30 (Typ.)(Tr/Td) |
| kut gledanja | 60/60/50/35 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 1 pcsCCFLWithout Driver |
| signalno sučelje | TFT Specific Analog RGB, 30 pins |
| ulazni napon | 3.3/3.3/5.0/15.0/-12.0V (Typ.)(VCC/VDD1/VDD2/VGH/VGL) |
| primjena | CNS |
