| Broj dijela | OEL9M0039-Y-E |
| Marka | Other |
| Veličina | 1.5 |
| Primjena | MPH |
| Rezolucija | 128×128 |
| Sastav | OLED |
| Svjetlina | 60 |
| CR | 10000:1 |
| Boje | Grayscale(Y) |
| Pozadinsko osvjetljenje | self |
| Sučelje | CPU/SPI |
| marka panela | TRULY |
| panelni model | OEL9M0039-Y-E |
| vrsta panela | PM-OLED , OLED |
| veličina ploče | 1.5 inch |
| rezolucija | 128×128 |
| aktivno područje | 26.86×26.86 mm |
| obris | 34.9×37.8×1.6 mm |
| površinski | |
| svjetlina | 60 cd/m² (Typ.) |
| omjer kontrasta | 10000 : 1 (Min.) |
| boje prikaza | Grayscale(Y) (4-bit) |
| kut gledanja | 80/80/80/80 (Min.)(L/R/U/D) |
| frekvencija | 100Hz |
| vozač ic | COG Built-in SSD1329Z |
| signalno sučelje | 8-bit 6800/8080 parallel, SPI, 25 pins |
| ulazni napon | 3.0/3.0/13.0V (Typ.)(VDD/VDDIO/VCC) |
| primjena | MPH |
