| Broj dijela | NL6448AC20-06 |
| Marka | NLT |
| Veličina | 6.5 |
| Primjena | IA |
| Rezolucija | 640×480 |
| Sastav | LCM |
| Svjetlina | 200 |
| CR | 150:1 |
| Boje | 4096/262K |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | TTL |
| marka panela | NEC |
| panelni model | NL6448AC20-06 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 6.5 inch |
| rezolucija | 640(RGB)×480 , VGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 132.48×99.36 mm |
| obris | 178.8×126.8 mm |
| površinski | |
| svjetlina | 200 cd/m² (Typ.) |
| omjer kontrasta | 150:1 (Typ.) |
| boje prikaza | 4096/262K (4-bit / 6-bit), CIE193145% |
| vrijeme odziva | 40 (Typ.)(Tr) |
| kut gledanja | 50/50/35/45 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 2 pcsCCFLEmbedded (Inverter) |
| signalno sučelje | CMOS (1 ch, 4/6-bit), 31 pins |
| ulazni napon | 5.0V (Typ.) |
| primjena | IA |
