| Broj dijela | NL128102AC29-17 |
| Marka | NLT |
| Veličina | 19.0 |
| Primjena | IA |
| Rezolucija | 1280×1024 |
| Sastav | LCM |
| Svjetlina | 800 |
| CR | 1000:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | NLT |
| panelni model | NL128102AC29-17 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 19.0 inch |
| rezolucija | 1280(RGB)×1024 , SXGA |
| način prikaza | UA-SFT, Normally Black, Transmissive |
| aktivno područje | 376.32×301.056 mm |
| obris | 396×324×18.5 mm |
| površinski | Antiglare, Hard coating (2H) |
| svjetlina | 800 cd/m² (Typ.) |
| omjer kontrasta | 1000:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193172% |
| vrijeme odziva | 14/11 (Typ.)(Tr+Td) |
| kut gledanja | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | WLEDEmbedded (LED Driver) |
| signalno sučelje | LVDS (2 ch, 8-bit), 30 pins |
| ulazni napon | 5.0V (Typ.) |
| primjena | IA |
