| Broj dijela | NL10276AC30-07 |
| Marka | NLT |
| Veličina | 15.0 |
| Primjena | DMPC |
| Rezolucija | 1024×768 |
| Sastav | LCM |
| Svjetlina | 400 |
| CR | 300:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | TTL |
| marka panela | NEC |
| panelni model | NL10276AC30-07 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 15.0 inch |
| rezolucija | 1024(RGB)×768 , XGA |
| način prikaza | Normally Black, Transmissive |
| aktivno područje | 304.128×228.096 mm |
| obris | 330×256×30 mm |
| površinski | Hard coating (2H) |
| svjetlina | 400 cd/m² (Typ.) |
| omjer kontrasta | 300:1 (Typ.) |
| boje prikaza | 16.7M (6-bit + Hi-FRC), CIE193160% |
| vrijeme odziva | 10/10 (Typ.)(Tr/Td) |
| kut gledanja | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 8 pcsCCFLEmbedded (Inverter) |
| signalno sučelje | TTL (2 ch, 8-bit), 75 pins |
| ulazni napon | 5.0V (Typ.) |
| primjena | DMPC |
