| Broj dijela | M270HGE-L30 |
| Marka | Innolux |
| Veličina | 27.0 |
| Primjena | DMPC |
| Rezolucija | 1920×1080 |
| Sastav | LCM |
| Svjetlina | 300 |
| CR | 1200:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | CHIMEI INNOLUX |
| panelni model | M270HGE-L30 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 27.0 inch |
| rezolucija | 1920(RGB)×1080 , FHD |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 597.888×336.312 mm |
| obris | 630×368.2×14.6 mm |
| površinski | Antiglare (Haze 25%), Hard coating (3H) |
| svjetlina | 300 cd/m² (Typ.) |
| omjer kontrasta | 1200:1 (Typ.) |
| boje prikaza | 16.7M (6-bit + Hi-FRC), CIE193172% |
| vrijeme odziva | 1.5/3.5 (Typ.)(Tr/Td) |
| kut gledanja | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 4 stringsWLEDWithout Driver |
| signalno sučelje | LVDS (2 ch, 8-bit), 30 pins |
| ulazni napon | 5.0V (Typ.) |
| primjena | DMPC |
| M270H3-L01 | Innolux | 27.0 | 1920×1080 |
| M270HGE-L20 | Innolux | 27.0 | 1920×1080 |
| M270HGE-L30 | Innolux | 27.0 | 1920×1080 |
| M270HHF-L10 | Innolux | 27.0 | 1920×1080 |
| M270HVN02.0 | AUO | 27.0 | 1920×1080 |
| M270HVN02.1 | AUO | 27.0 | 1920×1080 |
| M270HW01 V0 | AUO | 27.0 | 1920×1080 |
| M270HW02 V0 | AUO | 27.0 | 1920×1080 |
| M270HW02 V1 | AUO | 27.0 | 1920×1080 |
| M270HW02 V3 | AUO | 27.0 | 1920×1080 |
| LC215EUE-TEA1 | LG Display | 21.5 | 1920×1080 |
| LM170E03-TLL1 | LG Display | 17.0 | 1280×1024 |
| LM215WF1-TLB1 | LG Display | 21.5 | 1920×1080 |
| LM250WF3-TLA1 | LG Display | 25.0 | 1920×1080 |
| LM340UW2-SSA1 | LG Display | 34 | 3440×1440 |
| LTM170EU-L21 | Samsung | 17.0 | 1280×1024 |
| M190MWW3 R0 | IVO | 19.0 | 1440×900 |
| M215XTN01.0 | AUO | 21.5 | 1366×768 |
| MT215DW01 V.1 | Innolux | 21.5 | 1920×1080 |
| NL10276AC24-05 | NLT | 12.1 | 1024×768 |
