| Broj dijela | LW700AT9901 |
| Marka | Innolux |
| Veličina | 7.0 |
| Primjena | DPF |
| Rezolucija | 800×480 |
| Sastav | LCM |
| Svjetlina | 300 |
| CR | 400:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | CHIMEI INNOLUX |
| panelni model | LW700AT9901 1 Compatible model |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 7.0 inch |
| rezolucija | 800(RGB)×480 , WVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 152.4×91.44 mm |
| obris | 165×104×7.09 mm |
| površinski | |
| svjetlina | 300 cd/m² (Typ.) |
| omjer kontrasta | 400:1 (Typ.) |
| boje prikaza | 262K (6-bit), CIE193145% |
| vrijeme odziva | 3/15 (Typ.)(Tr/Td) |
| kut gledanja | 70/70/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 3S8PWLEDWithout Driver |
| signalno sučelje | TTL (1 ch, 6-bit), 40 pins |
| ulazni napon | 3.3V (Typ.) |
| rohs: | |
| primjena | DPF |
