| Broj dijela | LTV350QV-F09 |
| Marka | Samsung |
| Veličina | 3.5 |
| Primjena | DSC |
| Rezolucija | 320×240 |
| Sastav | LCM |
| Svjetlina | 320 |
| CR | 300:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | SAMSUNG |
| panelni model | LTV350QV-F09 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 3.5 inch |
| rezolucija | 320(RGB)×240 , QVGA |
| način prikaza | TN, Normally White, TMR |
| aktivno područje | 70.08×52.56 mm |
| obris | 76.9×63.9×4.45 mm |
| površinski | Hard coating (3H) |
| svjetlina | 320 cd/m² (Typ.) |
| omjer kontrasta | 300 : 1 (Typ.) |
| boje prikaza | 16.7M (8-bit) |
| vrijeme odziva | 25 (Typ.)(Tr+Td) |
| kut gledanja | 60/60/50/55 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 6S1PWLEDWithout Driver |
| signalno sučelje | Parallel RGB (1 ch, 8-bit) + SPI, 60 pins |
| ulazni napon | 3.3/4.9/18.0/-10.0V (Typ.)(VCC/DDVDH/VGH/VGL) |
| primjena | DSC |
| GCX123AKQ-E | JDI | 3.5 | 240×320 |
| LQ035Q3DG02A | SHARP | 3.5 | 320×240 |
| LTV350QV-F02 | Samsung | 3.5 | 320×240 |
| LTV350QV-F04 | Samsung | 3.5 | 320×240 |
| LTV350QV-F05 | Samsung | 3.5 | 320×240 |
| LTV350QV-F07 | Samsung | 3.5 | 320×240 |
| LTV350QV-F09 | Samsung | 3.5 | 320×240 |
| LTV350QV-F0E | Samsung | 3.5 | 320×240 |
| TM035KDH04 | Tianma | 3.5 | 320×240 |
| TM035NDH04 | Tianma | 3.5 | 272×480 |
| A015AN03 V0 | AUO | 1.46 | 280×220 |
| A015AN04 V6 | AUO | 1.5 | 280×220 |
| A024CN02 VL | AUO | 2.4 | 480×234 |
| A027DN04 V3 | AUO | 2.7 | 320×240 |
| A030DN04 V0 | AUO | 3.0 | 320×240 |
| LQ035Q1DH01 | SHARP | 3.5 | 320×240 |
| PA025XSF | E Ink | 2.5 | 480×234 |
| PT035TN23 V.1 | Innolux | 3.5 | 320×240 |
| TM027CDH19 | Tianma | 2.7 | 320×240 |
| TM035KDH03-79 | Tianma | 3.5 | 320×240 |
