| Broj dijela | LTN170CT08-L01 |
| Marka | Samsung |
| Veličina | 17.0 |
| Primjena | NBPC |
| Rezolucija | 1920×1200 |
| Sastav | LCM |
| Svjetlina | 280 |
| CR | 600:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | RGB LED |
| Sučelje | LVDS |
| marka panela | SAMSUNG |
| panelni model | LTN170CT08-L01 1 Compatible model |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 17.0 inch |
| rezolucija | 1920(RGB)×1200 , WUXGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 367.2×229.5 mm |
| obris | 382.2×247.5×7 mm |
| stil oblika | Wedge (PCBA Bent, Depth ≥5.2mm) |
| površinski | Antiglare (Haze 40%), Hard coating (3H) |
| svjetlina | 280 cd/m² (Typ.) |
| omjer kontrasta | 600:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE1931110% |
| vrijeme odziva | 16 (Typ.)(Tr+Td) |
| kut gledanja | 70/70/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | RGB LEDEmbedded (LED Driver) |
| signalno sučelje | LVDS (2 ch, 8-bit), 40 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | NBPC |
| LTN170CT03-004 | Samsung | 17.0 | 1920×1200 |
| LTN170CT07-G01 | Samsung | 17.0 | 1920×1200 |
| LTN170CT08-001 | Samsung | 17.0 | 1920×1200 |
| LTN170CT08-D01 | Samsung | 17.0 | 1920×1200 |
| LTN170CT08-L01 | Samsung | 17.0 | 1920×1200 |
| LTN170WA-L01 | Samsung | 17.0 | 1440×900 |
| M170E5-L08 | Innolux | 17.0 | 1280×1024 |
| M170EG01 V0 | AUO | 17.0 | 1280×1024 |
| MT170EN01 V.9 | Innolux | 17.0 | 1280×1024 |
| B133EW03 V0 | AUO | 13.3 | 1280×800 |
| B141PW04 V0 HW0A | AUO | 14.1 | 1440×900 |
| HV150UX1-101 | HYDIS | 15.0 | 1600×1200 |
| LP141WX1-TL01 | LG Display | 14.1 | 1280×800 |
| LQ10W03A | SHARP | 10.4 | 1024×600 |
| LTM12C283 | TOSHIBA | 12.1 | 800×600 |
| LTN121W4-L01 | Samsung | 12.1 | 1280×800 |
| LTN154X1-L03 | Samsung | 15.4 | 1280×800 |
| LTN156HT01-201 | Samsung | 15.6 | 1920×1080 |
| M133NWN1 R3 | IVO | 13.3 | 1366×768 |
