| Broj dijela | LTN170BT08-G01 |
| Marka | Samsung |
| Veličina | 17.0 |
| Primjena | NBPC |
| Rezolucija | 1440×900 |
| Sastav | LCM |
| Svjetlina | 200 |
| CR | 600:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | LVDS |
| marka panela | SAMSUNG |
| panelni model | LTN170BT08-G01 2 Compatible model |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 17.0 inch |
| rezolucija | 1440(RGB)×900 , WXGA+ |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 367.2×229.5 mm |
| obris | 382.2×244.5×6.5 mm |
| stil oblika | Wedge (PCBA Bent, Depth ≥5.2mm) |
| površinski | Antiglare, Hard coating (3H) |
| svjetlina | 200 cd/m² (Typ.) |
| omjer kontrasta | 600:1 (Typ.) |
| boje prikaza | 262K (6-bit) |
| vrijeme odziva | 16 (Typ.)(Tr+Td) |
| kut gledanja | 45/45/20/45 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 1 pcsCCFLWithout Driver |
| signalno sučelje | LVDS (2 ch, 6-bit), 30 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | NBPC |
| B170PW03 V4 | AUO | 17.0 | 1440×900 |
| LTN170BT05-G01 | Samsung | 17.0 | 1440×900 |
| LTN170BT06-G01 | Samsung | 17.0 | 1440×900 |
| LTN170BT07-G01 | Samsung | 17.0 | 1440×900 |
| LTN170BT08-G01 | Samsung | 17.0 | 1440×900 |
| LTN170BT09-001 | Samsung | 17.0 | 1440×900 |
| LTN170BT10-001 | Samsung | 17.0 | 1440×900 |
| LTN170BT11-D01 | Samsung | 17.0 | 1440×900 |
| LTN170BT11-D03 | Samsung | 17.0 | 1440×900 |
| LTN170WA-L01 | Samsung | 17.0 | 1440×900 |
| B156XTN03.5 | AUO | 15.6 | 1366×768 |
| HB125WX1-200 | BOE | 12.5 | 1366×768 |
| HB140FH1-301 | BOE | 14.0 | 1920×1080 |
| HT140WXB-601 | BOE | 14.0 | 1366×768 |
| LT121SS-124 | Samsung | 12.1 | 800×600 |
| LTN121W1-L02 | Samsung | 12.1 | 1280×800 |
| LTN133AT23-X01 | Samsung | 13.3 | 1366×768 |
| LTN156FL02-L01 | Samsung | 15.6 | 3840×2160 |
| M125NWR2 R1 | IVO | 12.5 | 1366×768 |
| N156BGE-EB1 | Innolux | 15.6 | 1366×768 |
