| Broj dijela | LTN160HT03-001 |
| Marka | Samsung |
| Veličina | 16.0 |
| Primjena | NBPC |
| Rezolucija | 1920×1080 |
| Sastav | LCM |
| Svjetlina | 250 |
| CR | 600:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | LVDS |
| marka panela | SAMSUNG |
| panelni model | LTN160HT03-001 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 16.0 inch |
| rezolucija | 1920(RGB)×1080 , FHD |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 353.28×198.72 mm |
| obris | 365×214 mm |
| stil oblika | Wedge (PCBA Bent, Depth ≥5.2mm) |
| površinski | Antiglare (Haze 40%), Hard coating (3H) |
| svjetlina | 250 cd/m² (Typ.) |
| omjer kontrasta | 600:1 (Min.) |
| boje prikaza | 262K (6-bit), CIE193172% |
| vrijeme odziva | 8 (Typ.)(Tr+Td) |
| kut gledanja | 65/65/55/55 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 2 pcsCCFLWithout Driver |
| signalno sučelje | LVDS (2 ch, 6-bit), 30 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | NBPC |
