| Broj dijela | HT14X1B-201 |
| Marka | HYDIS |
| Veličina | 14.1 |
| Primjena | NBPC |
| Rezolucija | 1024×768 |
| Sastav | LCM |
| Svjetlina | 150 |
| CR | 200:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | LVDS |
| marka panela | BOE HYDIS |
| panelni model | HT14X1B-201 2 Compatible model |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 14.1 inch |
| rezolucija | 1024(RGB)×768 , XGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 285.696×214.272 mm |
| obris | 299×228×5.5 mm |
| stil oblika | Wedge (PCBA Bent, Depth ≥5.2mm) |
| površinski | |
| svjetlina | 150 cd/m² (Typ.) |
| omjer kontrasta | 200:1 (Min.) |
| boje prikaza | 262K (6-bit) |
| vrijeme odziva | 25/25 (Max.)(Tr/Td) |
| kut gledanja | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 1 pcsCCFLWithout Driver |
| signalno sučelje | LVDS (1 ch, 6-bit), 30 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | NBPC |
| B141XG03 V2 | AUO | 14.1 | 1024×768 |
| B141XG09 V0 | AUO | 14.1 | 1024×768 |
| B141XN01 V0 | AUO | 14.1 | 1024×768 |
| HT14X12-101 | HYDIS | 14.1 | 1024×768 |
| HT14X13-101 | HYDIS | 14.1 | 1024×768 |
| HT14X13-102 | HYDIS | 14.1 | 1024×768 |
| HT14X14-101 | HYDIS | 14.0 | 1024×768 |
| HT14X1B-201 | HYDIS | 14.1 | 1024×768 |
| LP141WX5-TLP2 | LG Display | 14.1 | 1280×800 |
| LTN141P4-L02 | Samsung | 14.1 | 1400×1050 |
| BT156GW02 V.0 | Innolux | 15.6 | 1366×768 |
| CLAA141WB11 | CPT | 14.1 | 1280×800 |
| LP140WH6-TJA1 | LG Display | 14.0 | 1366×768 |
| LP150X09-B2K3 | LG Display | 15.0 | 1024×768 |
| LP154W01-TLAE | LG Display | 15.4 | 1280×800 |
| LP156WF1-TLB2 | LG Display | 15.6 | 1920×1080 |
| LP201WE1-TLA1 | LG Display | 20.1 | 1680×1050 |
| LTD104EA5F | TOSHIBA | 10.4 | 1024×768 |
| LTN141P4-L02 | Samsung | 14.1 | 1400×1050 |
| TX38D88VC1GAA | KOE | 15.0 | 1024×768 |
