| Broj dijela | LTN121XL01-N03 |
| Marka | Samsung |
| Veličina | 12.1 |
| Primjena | NBPC |
| Rezolucija | 1024×768 |
| Sastav | LCM |
| Svjetlina | 300 |
| CR | 700:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | SAMSUNG |
| panelni model | LTN121XL01-N03 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 12.1 inch |
| rezolucija | 1024(RGB)×768 , XGA |
| način prikaza | PLS, Normally Black, Transmissive |
| aktivno područje | 245.76×184.32 mm |
| obris | 257.3×199.1×4.75 mm |
| površinski | Antiglare (Haze 25%), Hard coating (3H) |
| svjetlina | 300 cd/m² (Typ.) |
| omjer kontrasta | 700:1 (Typ.) |
| boje prikaza | 262K (6-bit), CIE193147% |
| vrijeme odziva | 30 (Typ.)(Tr+Td) |
| kut gledanja | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 9S4PWLEDEmbedded (LED Driver) |
| signalno sučelje | LVDS (1 ch, 6-bit), 40 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | NBPC |
| B121EW01 V0 | AUO | 12.1 | 1280×800 |
| HT121WX2-211 | HYDIS | 12.1 | 1280×800 |
| LB121S03-TL04 | LG Display | 12.1 | 800×600 |
| LTD121EA4XY | TOSHIBA | 12.1 | 1024×768 |
| LTD121EQ3B | TOSHIBA | 12.1 | 1280×800 |
| LTN121X1-L02 | Samsung | 12.1 | 1024×768 |
| LTN121XJ-L03 | Samsung | 12.1 | 1024×768 |
| LTN121XJ-L05 | Samsung | 12.1 | 1024×768 |
| LTN121XJ-L07 | Samsung | 12.1 | 1024×768 |
| LTN121XL01-N03 | Samsung | 12.1 | 1024×768 |
| B125XW01 V0 | AUO | 12.5 | 1366×768 |
| B154EW02 V7 | AUO | 15.4 | 1280×800 |
| LP154W01-TLAE | LG Display | 15.4 | 1280×800 |
| LP154WX7-TLP1 | LG Display | 15.4 | 1280×800 |
| LP156WF3-SLB3 | LG Display | 15.6 | 1920×1080 |
| LTN140AT01-G01 | Samsung | 14.0 | 1366×768 |
| LTN141AT08-001 | Samsung | 14.1 | 1280×800 |
| LTN154X3-L04 | Samsung | 15.4 | 1280×800 |
| N156B6-L06 | Innolux | 15.6 | 1366×768 |
| NL8060BC26-13 | NLT | 10.4 | 800×600 |
