| Broj dijela | LTN121AT11-801 |
| Marka | Samsung |
| Veličina | 12.1 |
| Primjena | NBPC |
| Rezolucija | 1280×800 |
| Sastav | LCM |
| Svjetlina | 300 |
| CR | 300:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | SAMSUNG |
| panelni model | LTN121AT11-801 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 12.1 inch |
| rezolucija | 1280(RGB)×800 , WXGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 261.12×163.2 mm |
| obris | 274.5×177.5×3.6 mm |
| površinski | Antiglare (Haze 25%), Hard coating (3H) |
| svjetlina | 300 cd/m² (Typ.) |
| omjer kontrasta | 300:1 (Min.) |
| boje prikaza | 262K (6-bit), CIE193145% |
| vrijeme odziva | 16 (Typ.)(Tr+Td) |
| kut gledanja | 45/45/20/30 (Min.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 6S4PWLEDEmbedded (LED Driver) |
| signalno sučelje | LVDS (1 ch, 6-bit), 40 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | NBPC |
| LTN121AP05-302 | Samsung | 12.1 | 1280×800 |
| LTN121AP06-301 | Samsung | 12.1 | 1280×800 |
| LTN121AT01-002 | Samsung | 12.1 | 1280×800 |
| LTN121AT02-A01 | Samsung | 12.1 | 1280×800 |
| LTN121AT04-001 | Samsung | 12.1 | 1280×800 |
| LTN121AT07-L02 | Samsung | 12.1 | 1280×800 |
| LTN121AT08 | Samsung | 12.1 | 1280×800 |
| LTN121AT10-301 | Samsung | 12.1 | 1280×800 |
| LTN121AT11-801 | Samsung | 12.1 | 1280×800 |
| LTN121AT11-803 | Samsung | 12.1 | 1280×800 |
| B121EW02 V0 | AUO | 12.1 | 1280×800 |
| B140XTN02.3 | AUO | 14.0 | 1366×768 |
| B156HB01 V0 | AUO | 15.6 | 1920×1080 |
| LP140WF3-SPD1 | LG Display | 14.0 | 1920×1080 |
| LQ170M1LA4B | SHARP | 17.0 | 1920×1200 |
| LTN125AT03-803 | Samsung | 12.5 | 1366×768 |
| LTN141W1-L02 | Samsung | 14.1 | 1280×800 |
| LTN156AT02-B04 | Samsung | 15.6 | 1366×768 |
| LTN170CT08-D01 | Samsung | 17.0 | 1920×1200 |
| N150X3-L09 | Innolux | 15.0 | 1024×768 |
