| Broj dijela | LTM270DL04 |
| Marka | Samsung |
| Veličina | 27.0 |
| Primjena | DMPC |
| Rezolucija | 2560×1440 |
| Sastav | LCM |
| Svjetlina | 300 |
| CR | 1000:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | SAMSUNG |
| panelni model | LTM270DL04 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 27.0 inch |
| rezolucija | 2560(RGB)×1440 , Quad-HD |
| način prikaza | PLS, Normally Black, Transmissive |
| aktivno područje | 596.736×335.664 mm |
| površinski | Antiglare (Haze 42%), Hard coating (3H) |
| svjetlina | 300 cd/m² (Typ.) |
| omjer kontrasta | 1000:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193172% |
| vrijeme odziva | 12 (Typ.)(Tr+Td) |
| kut gledanja | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | WLEDWithout Driver |
| signalno sučelje | LVDS (4 ch, 8-bit) |
| ulazni napon | 5.0V (Typ.) |
| primjena | DMPC |
