| Broj dijela | LTM184HL01 |
| Marka | Samsung |
| Veličina | 18.4 |
| Primjena | DMPC |
| Rezolucija | 1920×1080 |
| Sastav | LCM |
| Svjetlina | 350 |
| CR | 1000:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | SAMSUNG |
| panelni model | LTM184HL01 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 18.4 inch |
| rezolucija | 1920(RGB)×1080 , FHD |
| način prikaza | PLS, Normally Black, Transmissive |
| aktivno područje | 408.96×230.04 mm |
| obris | 443.4×266.5×4.3 mm |
| površinski | Antiglare (Haze 1%), Antireflection |
| svjetlina | 350 cd/m² (Typ.) |
| omjer kontrasta | 1000:1 (Typ.) |
| boje prikaza | 262K (6-bit), CIE193172% |
| vrijeme odziva | 16 (Typ.)(G to G) |
| kut gledanja | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 12S6PWLEDEmbedded (LED Driver) |
| signalno sučelje | LVDS (1 ch, 6-bit), 40 pins |
| ulazni napon | 5.0V (Typ.) |
| primjena | DMPC |
| LTM181E3-P01 | Samsung | 18.1 | 1280×1024 |
| LTM181E4-L01 | Samsung | 18.1 | 1280×1024 |
| LTM184HL01 | Samsung | 18.4 | 1920×1080 |
| LTM185AT01 | Samsung | 18.5 | 1366×768 |
| LTM185AT02 | Samsung | 18.5 | 1366×768 |
| LTM185AT04 | Samsung | 18.5 | 1366×768 |
| LTM185AT05 | Samsung | 18.5 | 1366×768 |
| LTN184KT01-F01 | Samsung | 18.4 | 1680×945 |
| LTN184KT01-J01 | Samsung | 18.4 | 1680×945 |
| LTN184KT02-T01 | Samsung | 18.4 | 1680×945 |
| CLAA260WU09M | CPT | 25.5 | 1920×1200 |
| LM170E03-TLL1 | LG Display | 17.0 | 1280×1024 |
| LM190WX1-TLL1 | LG Display | 19.0 | 1440×900 |
| LM200WD3-TLF2 | LG Display | 20.0 | 1600×900 |
| LM215DB-T02 | PANDA | 21.5 | 1920×1080 |
| LQ315D1JG03 | SHARP | 31.5 | 3840×2160 |
| M190EG02 V4 | AUO | 19.0 | 1280×1024 |
| MT190AW02 V.0 | Innolux | 19.0 | 1440×900 |
| TD170WGCB2 | TPO | 17.0 | 1280×1024 |
| TMS156WX1-02TC | Tianma | 15.6 | 1366×768 |
