| Broj dijela | LTM150XS-T01 |
| Marka | Samsung |
| Veličina | 15.0 |
| Primjena | DMPC |
| Rezolucija | 1024×768 |
| Sastav | LCM |
| Svjetlina | 200 |
| CR | 300:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | TTL |
| marka panela | SAMSUNG |
| panelni model | LTM150XS-T01 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 15.0 inch |
| rezolucija | 1024(RGB)×768 , XGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 304.128×228.096 mm |
| obris | 331.3×257.9×16.4 mm |
| površinski | Antiglare (Haze 12%), Hard coating (3H) |
| svjetlina | 200 cd/m² (Typ.) |
| omjer kontrasta | 300:1 (Typ.) |
| boje prikaza | 262K (6-bit) |
| vrijeme odziva | 10/35 (Typ.)(Tr/Td) |
| kut gledanja | 70/70/55/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 2 pcsCCFLWithout Driver |
| signalno sučelje | TTL (2 ch, 6-bit), 55 pins |
| ulazni napon | 3.3V (Typ.)(VDD) |
| primjena | DMPC |
