| Broj dijela | LM185WH1-TLF1 |
| Marka | LG Display |
| Veličina | 18.5 |
| Primjena | DMPC |
| Rezolucija | 1366×768 |
| Sastav | LCM |
| Svjetlina | 250 |
| CR | 1000:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | LVDS |
| marka panela | LG Display |
| panelni model | LM185WH1-TLF1 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 18.5 inch |
| rezolucija | 1366(RGB)×768 , WXGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 409.8×230.4 mm |
| obris | 430.4×254.6×13.5 mm |
| površinski | Antiglare, Hard coating (3H) |
| svjetlina | 250 cd/m² (Typ.) |
| omjer kontrasta | 1000:1 (Typ.) |
| boje prikaza | 16.7M (6-bit + Hi-FRC), CIE193172% |
| vrijeme odziva | 1.1/3.9 (Typ.)(Tr/Td) |
| kut gledanja | 85/85/75/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 2 pcsCCFLWithout Driver |
| signalno sučelje | LVDS (2 ch, 8-bit), 30 pins |
| ulazni napon | 5.0V (Typ.) |
| primjena | DMPC |
| LM185WH1-TLA1 | LG Display | 18.5 | 1366×768 |
| LM185WH1-TLC5 | LG Display | 18.5 | 1366×768 |
| LM185WH1-TLD1 | LG Display | 18.5 | 1366×768 |
| LM185WH1-TLD3 | LG Display | 18.5 | 1366×768 |
| LM185WH1-TLF1 | LG Display | 18.5 | 1366×768 |
| LM185WH1-TLF4 | LG Display | 18.5 | 1366×768 |
| LM185WH2-T2BB | LG Display | 18.5 | 1366×768 |
| LM185WH2-TLA1 | LG Display | 18.5 | 1366×768 |
| LM185WH2-TLD1 | LG Display | 18.5 | 1366×768 |
| LM185WH2-TLE2 | LG Display | 18.5 | 1366×768 |
| CLAA260WU09 | CPT | 25.5 | 1920×1200 |
| LC215DTCA | PANDA | 21.5 | 1920×1080 |
| LM195WD1-TLA1 | LG Display | 19.5 | 1600×900 |
| LTM150XO-L01 | Samsung | 15.0 | 1024×768 |
| LTM220M1-L02(Glare) | Samsung | 22.0 | 1680×1050 |
| M185XTN01.0 | AUO | 18.5 | 1366×768 |
| M260J2-L07 | Innolux | 25.5 | 1920×1200 |
| MT190EN02 V.W | Innolux | 19.0 | 1280×1024 |
| SVA156WX1-01TB | SVA-NEC | 15.6 | 1366×768 |
| TM150XG-22L01A | SANYO | 15.0 | 1024×768 |
