| Broj dijela | LTL101DL03-T01 |
| Marka | Samsung |
| Veličina | 10.1 |
| Primjena | PAD |
| Rezolucija | 2560×1600 |
| Sastav | LCM |
| Svjetlina | 370 |
| CR | 800:1 |
| Boje | 16.2M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | eDP |
| marka panela | SAMSUNG |
| panelni model | LTL101DL03-T01 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 10.1 inch |
| rezolucija | 2560RG(BW)×1600 , WQXGA |
| način prikaza | PLS, Normally Black, Transmissive |
| aktivno područje | 216.576×135.36 mm |
| obris | 232.22×156.92×5.2 mm |
| površinski | Glare (Haze 0%), Hard coating (2H) |
| svjetlina | 370 cd/m² (Typ.) |
| omjer kontrasta | 800:1 (Typ.) |
| boje prikaza | 16.2M (6-bit + FRC) |
| vrijeme odziva | 16 (Typ.)(Tr+Td) |
| kut gledanja | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 7S6PWLEDEmbedded (LED Driver) |
| signalno sučelje | eDP (4 Lanes), 45 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | PAD |
