| Broj dijela | LTI550HJ05 |
| Marka | Samsung |
| Veličina | 55 |
| Primjena | PID |
| Rezolucija | 1920×1080 |
| Sastav | LCM |
| Svjetlina | 450 |
| CR | 5000:1 |
| Boje | 1.07B |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | SAMSUNG |
| panelni model | LTI550HJ05 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 55 inch |
| rezolucija | 1920(RGB)×1080 , FHD |
| način prikaza | S-PVA, Normally Black, Transmissive |
| aktivno područje | 1209.6×680.4 mm |
| obris | 1245.75×717.52×23.3 mm |
| površinski | Antiglare (Haze 44%), Hard coating (3H) |
| svjetlina | 450 cd/m² (Typ.) |
| omjer kontrasta | 5000:1 (Typ.) |
| boje prikaza | 1.07B (8-bit + Hi-FRC), CIE193172% |
| vrijeme odziva | 10 (Typ.)(G to G) |
| kut gledanja | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | WLEDEmbedded (LED Driver) |
| signalno sučelje | LVDS (4 ch, 10-bit), 51 pins |
| ulazni napon | 12.0V (Typ.) |
| primjena | PID |
