| Broj dijela | LSC550FN05 |
| Marka | Samsung |
| Veličina | 55 |
| Primjena | LCTV |
| Rezolucija | 3840×2160 |
| Sastav | CELL |
| Svjetlina | 0 |
| CR | 4000:1 |
| Boje | 1.07B |
| Pozadinsko osvjetljenje | No B/L |
| Sučelje | V-by-One |
| marka panela | SAMSUNG |
| panelni model | LSC550FN05 |
| vrsta panela | a-Si TFT-LCD , CELL |
| veličina ploče | 55 inch |
| rezolucija | 3840(RGB)×2160 , UHD |
| način prikaza | SVA, Normally Black, Transmissive |
| aktivno područje | 1209.6×680.4 mm |
| obris | 1223.6×697.1 mm |
| površinski | Antiglare (Haze 2.3%), Hard coating (2H) |
| dubina stakla | 0.50+0.50 mm |
| transmisivnost | 4.6% (Typ.)(with Polarizer) |
| omjer kontrasta | 4000:1 (Typ.) |
| boje prikaza | 1.07B (8-bit + Dithering), CIE193168% |
| vrijeme odziva | 8 (Typ.)(G to G) |
| kut gledanja | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| signalno sučelje | V-by-One 8 lane, 51 pins |
| ulazni napon | 12.0V (Typ.) |
| primjena | LCTV |
