| Broj dijela | V546H1-LH2 |
| Marka | Innolux |
| Veličina | 55 |
| Primjena | LCTV |
| Rezolucija | 1920×1080 |
| Sastav | LCM |
| Svjetlina | 500 |
| CR | 4000:1 |
| Boje | 16.7M/1.07B |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | LVDS |
| marka panela | CMO |
| panelni model | V546H1-LH2 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 55 inch |
| rezolucija | 1920(RGB)×1080 , FHD |
| način prikaza | Super MVA, Normally Black, Transmissive |
| aktivno područje | 1209.6×680.4 mm |
| obris | 1267.6×738.4×41.5 mm |
| površinski | Antiglare (Haze 11%), Hard coating (3H) |
| svjetlina | 500 cd/m² (Typ.) |
| omjer kontrasta | 4000:1 (Typ.) |
| boje prikaza | 16.7M/1.07B (8-bit / 8-bit + Hi-FRC), CIE193172% |
| vrijeme odziva | 4.5 (Typ.)(G to G) |
| kut gledanja | 88/88/88/88 (Typ.)(CR≥20)(L/R/U/D) |
| frekvencija | 120Hz (60Hz Input) |
| tip svjetiljke | 22 pcsCCFLEmbedded (Inverter) |
| signalno sučelje | LVDS (2 ch, 10-bit), 51 pins |
| ulazni napon | 12.0V (Typ.) |
| primjena | LCTV |
