| Broj dijela | LQ10PX01 |
| Marka | SHARP |
| Veličina | 10.4 |
| Primjena | PRO |
| Rezolucija | 1024×768 |
| Sastav | LCM |
| Svjetlina | 0 |
| CR | 60:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | No B/L |
| Sučelje | TTL |
| marka panela | SHARP |
| panelni model | LQ10PX01 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 10.4 inch |
| rezolucija | 1024(RGB)×768 , XGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 211.968×158.976 mm |
| obris | 283×215.6 mm |
| površinski | |
| svjetlina | 0 cd/m² |
| omjer kontrasta | 60:1 (Min.) |
| boje prikaza | 262K (6-bit) |
| vrijeme odziva | 30/50 (Typ.)(Tr/Td) |
| kut gledanja | 45/45/30/10 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | No B/L |
| signalno sučelje | Parallel RGB (1 ch, 6-bit), 36 pins |
| ulazni napon | 5.0/12.0V (Typ.)(VCC/VDD) |
| primjena | PRO |
